Toyota 2kd Engine 2008

The 2008 2KD engine typically refers to the 2KD-FTV, a 2.5-liter, 16-valve common rail direct injection turbocharged DOHC diesel engine used in vehicles like the Toyota Hilux, Fortuner, Innova, Hiace, and Dyna. It’s known for producing around 88 kW (118 hp) and 325 N⋅m (240 lb⋅ft) of torque, though specific outputs can vary slightly depending on the application and transmission.

Key details about the 2008 2KD-FTV engine:
  • Engine Code: 2KD-FTV.
  • Type: 2.5-liter, 4-cylinder, DOHC, 16-valve, common rail, direct injection, turbo diesel engine.
  • Displacement: 2494 cc.
  • Bore x Stroke: 92 x 93.8mm.
  • Compression Ratio: 18.5 to 1.
  • Horsepower & Torque: Typically around 88 kW (118 hp) at 3600 rpm and 325 N⋅m (240 lb⋅ft) of torque at 2000 rpm, though some variants may have slightly different figures, like 75 kW (101 hp) and 260 N⋅m (192 lb⋅ft) with automatic transmissions.
  • Applications: Commonly found in the Toyota Hilux, Fortuner, Innova, Hiace, and Dyna.
  • Availability: In 2008, this engine was widely available in models like the Toyota Hilux Vigo.





The 2008 2KD engine, specifically the 2KD-FTV, is a 2.5-liter, 4-cylinder, DOHC, 16-valve common rail direct injection turbocharged diesel engine with a displacement of 2494cc. It typically produces a maximum power of 75 kW (101 hp) at 3600 rpm and a maximum torque of 260 Nm (192 lbf⋅ft) at 1600-2400 rpm.

Key Specifications of the 2008 2KD-FTV Engine:
  • Engine Type: Diesel, Common Rail Direct Injection, Turbocharged, Intercooled (often).
  • Displacement: 2494 cc.
  • Cylinders: 4.
  • Valves: 16.
  • Configuration: DOHC (Double Overhead Camshaft).
  • Maximum Power: 75 kW (101 hp) at 3600 rpm.
  • Maximum Torque: 260 Nm (192 lbf⋅ft) at 1600-2400 rpm.
  • Compression Ratio: 18.5:1.
  • Bore x Stroke: 92 mm x 93.8 mm.
  • Fuel Type: Diesel.
  • Electrics: 12 Volts.
  • Redline: 4400 RPM.
Note that some versions, particularly those with variable nozzle turbochargers and intercoolers, saw higher power and torque figures. The engine lifespan is estimated around 300,000 km, and its weight is approximately 250 kg.
